Sale!
AVMATRIX PVS0403U Multi-Format Video Mixer Switcher
Original price was: KSh96,999.00.KSh84,999.00Current price is: KSh84,999.00.
The PVS0403U allows for video switching up to 1080p60 video with embedded audio or with additional audio from up to two analog stereo 3.5mm mic/line inputs. With a multiview HDMI output you can preview your functions on an additional monitor. Additionally, it provides one with two HDMI program outputs thus enabling the simultaneous sending of signals to a display for live events and a recording terminal for editorial consideration. There is also a USB-C video output to connect to a computer for video capture and livestreaming, while a LAN port enables you to control the switcher using software via IP. Logo overlays are supported from a variety of different image file formats, including PNG, JPG, and BMP, and you have the option of capturing up to 16 screenshots and storing up to 16 images using the USB-A input with 39 default patterns and two color generators.
AVMATRIX PVS0403U Multi-Format Video Mixer Switcher
AVMATRIX PVS0403U Multi-Format Video Mixer Switcher
Description
AVMATRIX PVS0403U Multi-Format Video Mixer Switcher Add professional video switching and audio mixing flexibility to your concert productions, house of worship, educational forum, or live sports programming with this HVS0403U Micro 4-Channel SDI & HDMI Video Switcher from AVMATRIX. Boasting two HDMI and two SDI autodetectable inputs, the HVS0403U is a compact and user-friendly video switcher loaded with an integrated 10.1″ Full HD IPS LCD monitor and many powerful features, including luma and chroma keying, mix/fade/wipe effects, audio mixing, and a picture-in-picture or picture-on-picture layout, using tactile functions such as auto and cut transitions or the T-bar.
Highlights
- 10.1 inch FHD IPS LCD monitor
- 2× HDMI & 2× 3G-SDI inputs, support auto-detected
- 2× HDMI PGM output, 1× HDMI multi view out, 1× USB type-C output
- All outputs are configurable and assignable
- USB for capturing and streaming on PC
- Upstream key: Luma key, Chroma key, PIP×2/ POP Downstream key and LOGO overlay
- T-bar/ Auto/ Cut transitions; various effects: WIPE(11×2 patterns)/ MIX/ DIP
- Audio mixer: 2× SDI, 2× HDMI embedded audio and 2× MIC/line In; audio delay available
- Media library: 39 default patterns, 16 imported images, 16 captured images, 2 color generators
- LAN port for PC software remote control
- FTB/ MUTE/ STILL/ GPIO for tally
AVMATRIX PVS0403U Multi-Format Video Mixer Switcher
10.1″ IPS Full HD Display
The integrated display enables you to clearly view preview, program with audio bar, multiview, clock, and menu settings.
Scaled Output and Multiview
AVMATRIX PVS0403U 4-Channel SDI switcher supports multiview formats, including 1080p, 1080i, 720p, and 480p HDMI and SDI signals. Each output supports up/down scaling and can be configured as HDMI/SDI source, PVW, PGM, clean PGM, and multiview.
USB Capture for Streaming
Connect the switcher to a computer via the USB Type-C output and use software like OBS, Pot Player, or v Mix to realize livestreaming on YouTube, Facebook, Twitter, and other social media platforms.
Upstream and Downstream Keying
AVMATRIX PVS0403U 4-Channel SDI switcher supports chroma and luma key for keying off blue/green and black background colors for virtual studio or live event applications.
Transition Effects
There are wipe (11 x 2 patterns), mix, and dip transition effects available using the T-bar or Auto button function, and users can also transition to different shots by switching via the Cut button.
Powerful Media Management
The media management functions feature 39 preset patterns, and users can import images from a USB thumb drive or capture and store the screenshot image originating from SDI1, SDI2, HDMI3, HDMI4, clean PGM, and PGM.
